868MHz fiberglass antenna covers 826–898MHz for LoRa stations and telemetry. This 868MHz fiberglass antenna delivers 5.5dBi gain, VSWR ≤1.5, and 50W handling. The 868MHz fiberglass antenna uses a 400mm weatherproof radome and N male connector for stable outdoor coverage.
Dongguan Renfeng Electronic Technology Co., Ltd.
868MHz 5.5dBi High-Performance Omnidirectional Fiberglass Antenna
Outdoor omnidirectional 868MHz 5.5dBi fiberglass antenna covering 826–898MHz, with N male connector and 50W power handling. Its fiberglass radome is designed for LoRa stations and telemetry, providing stable all-around coverage for fixed outdoor installations.
Contact us
Contact us
| Antenna Type | Fiberglass Antenna |
|---|---|
| Frequency Range | 826-898MHz |
| Gain | 5.5dBi |
| VSWR | ≤1.5 |
| Connector | N Male |
| Polarization | Vertical |
| Radiation Pattern | Omnidirectional |
| Max Input Power | 50W |
| Cable | |
| Cable Length | |
| Dimensions | 400mm |
| Weight | 145±5g |
| Material | Fiberglass |
| Operating Temperature | -40°C to +80°C |
| Storage Temperature | -40°C to +85°C |
