915MHz PCB antenna covers 860–940MHz for LoRaWAN gateways and remote meters. This 915MHz PCB antenna uses a 95×14mm board, IPEX-1 connector, and 120mm RF1.13 cable for secure internal mounting. The 915MHz PCB antenna provides 3dBi all-around performance with reliable wideband integration.
Dongguan Renfeng Electronic Technology Co., Ltd.
915MHz 3dBi PCB Embedded Antenna with 120mm Cable
Embedded 915MHz 3dBi PCB embedded antenna covering 860–940MHz, with IPEX-1 connector and 120mm RF1.13 cable. Its 95mm×14mm PCB form factor supports LoRaWAN gateways and remote meters, with customizable cable length for compact device integration.
Contact us
Contact us
| Antenna Type | PCB Embedded Antenna |
|---|---|
| Frequency Range | 915MHz 860-940MHz |
| Gain | 3dBi |
| VSWR | ≤2.0 |
| Connector | IPEX-1 |
| Polarization | Linear |
| Radiation Pattern | Omnidirectional |
| Max Input Power | 2W |
| Cable | RF1.13 |
| Cable Length | 120mm (customizable) |
| Dimensions | 95mm×14mm |
| Weight | 3g |
| Material | PCB |
| Operating Temperature | -30°C to +75°C |
| Storage Temperature | -30°C to +75°C |
